Air Suspension Crimping Machine With Screen Fitting Crimping Hose Crimper Rubber
Product Details:
| Place of Origin: | Guangdong, China(Mainland) |
| Brand Name: | TM |
| Model Number: | all kinds of model Mercedes , BMW , Audi , Land rover , Toyota |
| Certifiion: | TS16949 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Standard export plywood crate |
| Delivery Time: | Within 1 month after received your payment |
| Payment Terms: | T/T, Western Union, PayPal |
| Supply Ability: | 3,000pcs per month |
|
Detail Information |
|||
| Size: | L850*W900*H1300mm | Crimping Range: | 20MM-175MM |
|---|---|---|---|
| Weight: | 220kg-250kg | Crimping Force: | 100T |
| Acurracy: | 0.05mm | Voltage: | 380V |
| Power: | 34kw | System Pressure: | 30Mpa |
| High Light: | hydraulic hose crimp machine,heavy duty shock absorbers |
||
Product Description
Air Suspension Crimping Machine With Screen Fitting Crimping Hose Crimper Rubber
Production Description
Specifiion
| Crimping force : 100T | ||
| Max opening : 175mm | ||
| Crimping range : 20mm-175mm | ||
| Acurracy : 0.05mm | ||
| Standard dies sets : 10 (size customized) | ||
| Voltage : 380V | ||
| Power : 4kw | ||
| System pressure : 30Mpa | ||
| Operate mode : auto , manual , pedal | ||
| Weight : 300kg-350kgs | ||
| Dimension : L850*W900*H1300mm | ||
| Crimping way : Transverse withhold |
The brief introduction of high pressure hose crimping machine:
Crimping machine is mainly used for buckling processing for high pressure rubber pipe assembly in the mechanical engineering. It can also be used for buckling the two-way bends, especially large bends and irregular shape bends. This machine features small and portable appearance, big force, low noise and easy to operate. The buckling amount can be precise adjusted through a scale. It makes the mould base division to be more even through the double inclined plane eight-flap mould seat equipped with a high accuracy guiding device.
Notices
1. Add sufficiently 25g of 46# anti-abrasion hydraulic oil.(the original is the best).
2. When buckling, make the joint to loe the mould center as much as possible, the joint is not buckled on the hex nut.
3. Prevent tool and other foreign matter from entering the locking head.
4. After the work is finished for each time, the eight-block mould base must be made to extend to the greatest extent, this can make the spring to be at extension status. If not, the spring will be damage.
5. When working, the hand should not stretch into the locking head.
6. The power supply must be switched off when maintenance is done.
7. Be careful that three-phase machine can’t be in reverse. (Overhead view: motor fan rotates in clockwise direction that is the forward direction.)
This is our new hydraulic hose crimping machine, can crimp all types of hydraulic hoses.
1.Air spring crimping machine provided with die sets range for 1/4' to 1 1/4' ID hoses.
2.Double angular surface-swaging force up to 450T, powerful yet makes crimping easy.
3.Piston,Cylinder,All dies are wire cut after hardening and grinding.
4.Powder coating body give it a Futuristic sleek & stylish looks.
1. We can translate your original drawing, and offer the best suggestion on design.
2. We have set up a quality management system assuring the quality of all the products and services provided.
3. All of our products must be checked carefully before shipping.
4. We provide 1 year warranty.
Company Information:
Guangzhou Tech Master Auto Parts Co. Ltd. is a professional company specializing in developing, producing and exporting air suspension parts, such as, air spring, air strut, air shock absorber, air compressor, power steering pump, steering rack, control arms, other spare parts and suspension accessories, especially for Mercedes-Benz, BMW, Audi, Land Rover, Lincoln, and Ford. We also supply other models of the air suspension parts and a series of high-grade heavy truck front and rear air springs.
FAQ
1. What does this machine used for?
It can be used to repair or manufacture air suspensions, air aprings for cars and trucks. and aslo the industrial hydraulic hose pipes.
2. What is Voltage of this machine?
Original Voltage is 380V, but we can also make according to your requirements
3. Is it simple to learn to opearte this machine?
It is easy for operating. we will give detailed instruction and CD to show our customers how to operate
4. How to determine the dimensions of the die sets?
We process the die sets according to your dimensions or you tell us what products you want to crimp, then we can determine the size.
5. how are you going to package the machine to prevent damage during shipping?
we will pack the machine with strong wooden box with pallet to insure the safety of the machine during shipping.
