|Crimping Rang::||20MM-175MM||Model::||Suspension Spring|
|OEM Code::||Hydraulic Hose Crimping Machine||Power::||4KW|
|Standard Dies Sets::||10 (size Customized)||Application::||For All Kinds Of Car Mode, Benz, BMW, Audi, VW, Toyato, LandRove|
|Warranty::||12 Months||Place Of Origin:||Canton China|
|Crimping Force::||100T||Delivery::||3-5 Days|
|Package::||Neutral Packing Or As Requirement||Acurracy::||0.05mm|
|Voltage::||380V And 220V(according To Customer Requests)||System Pressure::||30Mpa|
|Weight::||300kg-350kgs||System Pressure::||30 Mpa|
Hydraulic hose crimping machine suppliers with factory price for air suspension kits crimping machine
Crimping Force: 100T
Crimping Way : Transverse and Vertical withhold
This machine can be valid to place rings all the usual models such as Mercedes, For Audi, For Landrover, For BMW and etc.
The brief introduction of high pressure hose crimping machine
Crimping machine connect rubber, plastic and steel rings through hydraulic power. It applies locking pressure through the mold of crimping machine to swage the metal joint on the matched auto air springs and high-pressure oil pipes, so as to complete the installation assembly.
It’s applicable to air spring, all kinds of machinery high and low pressure oil tube, air tube, automobile power steering tube, oil pipe, gasoline supply pipe, as well as buckling of construction fittings and hot water pipe.
It’s also widely used in vehicle, engineering machinery, hydraulic machinery, agricultural machinery and so on.
Real Photos of Products
Installation and Operation
1. Connect the electric source well as per the machine requirements, to make the direction of the motor rotation to be consistent with the rotation direction marking, and grounding protection shall be done.
2. Regulating the scale
The scale is used for regulating the amount of the buckling. When it is regulated clockwise, the buckling amount will decrease, when it is regulated anticlockwise, the buckling amount will increase. The scale is connected together with oil cylinder end cover through three socket head screws and three springs on the scale base. When using a hand to pull the scale (vertical to the oil cylinder end cover direction), the scale can flexibly leave from the oil cylinder end cover. When releasing the scale, the scale will be recovered relying on spring force. Before the machine is turned on, inspect carefully if the scale telescoping is flexible and if the lead connection is reliable.
3. The primary scale is turned within 0 line of the secondary scale, turn the machine on for test run, and observe if all actions are normal. If when the piston conducts reciprocating movement, there is a crawling phenomenon, the bleed screw on the oil cylinder top shall be unscrewed for exhausting air.
4. Pressure regulation
The buckling pressure and opening mould pressure will be regulated through two knobs at the back of the oil cylinder, when it is regulated clockwise, the pressure will increase, when it is regulated anticlockwise, the pressure will decrease (The pressure has already been well regulated when ex-factory).
This is our new hydraulic hose crimping machine, can crimp all types of
1.Air spring crimping machine provided with die sets range for 1/4' to 1 1/4' ID hoses.
2.Double angular surface-swaging force up to 450T, powerful yet makes crimping easy.
3.Piston,Cylinder,All dies are wire cut after hardening and grinding.
4.Powder coating body give it a Futuristic sleek & stylish looks.
The finished products have passed the performance test, brust test, endurance test, leaking test and aging test, Performance test,Brust test,Endurance test,Leaking test.
So, the products in our company are guaranteed of their quality.
Our Customers Normally Ask These Questions About the Machine:
1. What does this machine used for?
It is can be uased to repair or manufacture air suspension, air spring for cars and truck. And also the industril hydraulic hose pipes
2. What is Voltage of this machine?
Original Voltage is 380V, but we can slao make according to your requirements.
3. Is it simple to learn to operate this machine?
It is easy for operating. We will give detailes instruction and CD to show our customers how to operate.
4. How to determine the dimensions of the die sets?
We process the die sets according to your dimendions or you tell us whta products you want to crimp, then we can determine the size.
5. How are you going to package the machine to prevent damage during shipping?
We will pack the machine with strong eooden box with pallet to insure the safety of the machine during shipping.
